The 63A Automatic Transfer Switch (ATS) is a high-performance solution for solar electric systems, offering fast and efficient power transitions. Designed for both residential and commercial solar installations, it supports flexible current options and AC 110V / 230V voltage. This ATS features overload protection, short circuit protection, and remote control capabilities for enhanced system management. We offer customized solutions to suit your specific requirements, alongside reliable logistics and packaging services to ensure safe and timely delivery.
ATS
KCISE
ATS
| Quantity: | |
|---|---|
| Parameter | Value |
|---|---|
| Product Name | 63A Automatic Transfer Switch (ATS) |
| Current (Ie) | 32A / 40A / 50A / 63A |
| Rated Operating Voltage (Ue) | AC 110V / 230V |
| Rated Insulating Voltage (Ui) | AC 690V |
| Impulse Withstand Voltage | 8kV |
| Switching Time | 50ms |
| Frequency | 50-60Hz |
| Mechanical Life | 8000 cycles |
| Electrical Life | 1500 cycles |
| Usage Category | AC-31B |
| Application | Suitable for Solar Electric Systems |
KCISE presents the 63A Automatic Transfer Switch (ATS), ideal for solar electric systems. This ATS ensures seamless operation with options for 32A, 40A, 50A, and 63A currents, making it adaptable to different solar power configurations. It operates at AC 110V / 230V and is rated for AC 690V insulating voltage.
With a fast 50ms switching time and an impulse withstand voltage of 8kV, the ATS offers reliable protection against voltage surges. It boasts a mechanical life of 8000 cycles and an electrical life of 1500 cycles, ensuring long-lasting performance.
This automatic transfer switch is designed for solar energy solutions, with advanced features such as overload protection, short circuit protection, and an intelligent alarm system. It’s also equipped with remote control capabilities, allowing efficient management of your solar power system.
The 63A Automatic Transfer Switch (ATS) ensures consistent performance with a mechanical life of 8000 cycles and an electrical life of 1500 cycles, making it ideal for solar energy systems that require reliable, high-performance components.
Designed with a 50ms switching time, this ATS allows for quick transitions between power sources, minimizing system disruptions in solar power applications and ensuring seamless operation.
With built-in overload protection, short circuit protection, and an intelligent alarm system, the 63A ATS is engineered to protect your solar electric system from power surges, ensuring enhanced safety and reliability.
The 63A ATS offers flexibility, supporting AC 110V / 230V operating voltage and a range of current options (32A, 40A, 50A, 63A). This makes it suitable for various solar installations, from small residential systems to larger commercial projects.
The 63A Automatic Transfer Switch (ATS) is built for reliability. With a mechanical life of 8000 cycles and 1500 electrical cycles, it ensures longevity in demanding solar electric systems, minimizing the need for frequent replacements or repairs.
This ATS is equipped with overload protection, short circuit protection, and an intelligent alarm system, offering robust defense for your solar power installations. These features protect against electrical issues, helping to maintain system stability and prevent costly downtime.
Our 63A ATS features an ultra-fast 50ms switching time, ensuring minimal disruption during power source transitions. It is specifically designed for high-performance in solar energy solutions, keeping your system running smoothly with efficient power distribution.
With compatibility for AC 110V / 230V voltages and current options of 32A, 40A, 50A, 63A, this ATS is versatile enough to support both small-scale residential solar systems and larger commercial solar projects, providing optimal performance across diverse setups.
This 63A ATS comes with remote control functionality, allowing users to monitor and manage solar energy systems remotely. This feature streamlines system adjustments, improves operational efficiency, and enhances user convenience in managing solar energy resources.
The 63A ATS features a fast 50ms switching time, ensuring quick transitions between power sources and minimal downtime in solar power systems.
Yes, the 63A ATS is designed for residential and commercial solar installations, offering flexible current options (32A, 40A, 50A, 63A) and voltage compatibility (AC 110V / 230V).
The 63A ATS includes overload, short circuit protection, and an intelligent alarm system, ensuring reliable protection for your solar electric system.
