Ewelink Single Phase 63A WIFI Smart Energy Meter Circuit Breaker Timer Relay with Leakage Protection
Home » Products » MCB » Smart Miniature Circuit Breaker » Ewelink Single Phase 63A WIFI Smart Energy Meter Circuit Breaker Timer Relay with Leakage Protection

Ewelink Single Phase 63A WIFI Smart Energy Meter Circuit Breaker Timer Relay with Leakage Protection

Product Features:
*Protocol: Wi-Fi / IEEE 802 11 b / 2.4GHz
* Rated Operating Voltage Range: AC 90V-240V
* Control Type: Remote Control, Manual
* Poles Description: 1 P+N (N Pole Pass-through)
* Customization: Lora/ SigMesh / RS485 / RJ45
* Model selection: On/Off Type (1 ~63A current adjustable)
* Size: 82 x 50 x 18mm (with mounting clip)

  • SMC8-63A/1P

  • KCISE

  • SMMCB001

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button


General

A eWeLink smart circuit breaker is an electronic device that operates the circuit breaker through remote control to turn on or off, monitor and collect the use status of the circuit and load equipment. Smart circuit breakers can feed back and record the information status of circuits and equipment through the Internet in real time.

Smart life Wifi Energy Meter Kwh Meter Wattmeter AVP Protection Leakage Voltage Protect Voice Alexa
1. Under voltage protection 150V-190V (adjustable) (default: 170V)

2. Over voltage proteciton 250V-300V (adjustable) (default:270)
3. Over current protection 1A-63A (adjustable) (default: 63A)
4. Reconnect time (delay on time): 5s-90s (default: 30s)
5.Electric leakage protection:10-99mA(This feature can be turned off)

6. Power display range:0-99999.9kw/h

  • Smart Home Automation: This EWELINK TUYA Timing Metering overload voltage protection WiFi Wireless Remote Control Smart Circuit Breaker switch allows users to control and monitor their electrical devices remotely using the Tuya/Ewelink smart app, compatible with Alexa and Google Home for seamless integration.

  • Advanced Safety Features: The product offers overload, voltage protection, and timer functions, ensuring the safe operation of electrical devices and preventing potential electrical hazards.

  • High-Quality Construction: With a high breaking capacity of 6kA and a 10,000-cycle electrical life, this circuit breaker is built to last and provide reliable performance.

  • Easy Installation: The compact design with a width of 18mm and installation on a 35mm DIN rail makes it easy to integrate into existing electrical systems.

  • User-Friendly Compatibility: Conveniently connect your devices via WiFi 2.4G and control them using the Tuya/Ewelink app, ensuring a hassle-free user experience for users.
